2017 Chevrolet Cruze Sedan Remote Start Kit

[Music] [Music] so chevy cruze the bcm is located right back in here so you're just going to simply pop the plastic panel off the bcm is right here and we're gonna plug into the bottom three right here so the white blue and the green so as you guys will notice our bcm has a bunch of colored connectors back in there which also represent the color connectors on our harness so we're going to be using the green the white and the blue here and those are the bottom three connectors there white blue green so all we need to do is unplug the factory connector from the bcm we're going to plug it into our harness and then the other end of our harness goes back into the bcm so this is basically just a t-harness there's a couple jumpers and connectors on here you guys are going to want to make sure that we are on the gm7 and gm12 tab here and then the gm8 is not used and then you guys will also noti
