Camera
Signal System:PAL/NTSC
Shutter time:1/3 s to 1/100,000 s
Slow shutter:Support
Lens:2.8 mm, horizontal FOV: 102°, vertical FOV: 53°, diagonal FOV: 124°
Lens Mount:M12
Adjustment Range:Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
Day& Night:IR cut filter with auto switch
Digital noise reduction:3D DNR
Focus:Fixed

Compression Standard
Video Compression:H.265+/H.265/H.264+/H.264/MJPEG
Video bit rate:32Kbps~16Mbps
Triple Streams:Yes

Image Settings:Saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser
Target Cropping:No
ROI:1 fixed region for main stream and sub-stream
Day/Night Switch:Day/Night/Auto/Schedule

Network
Protocols:TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
General Function:One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering
System Compatibility:ONVIF (Profile S, Profile G),ISAPI

Interface
Communication Interface:1 RJ45 10M / 100M Ethernet interface
Smart Feature-set
Behavior Analysis:Line crossing detection, intrusion detection
Line Crossing Detection:Cross a pre-defined virtual line
Intrusion Detection:Enter and loiter in a pre-defined virtual region

General
Operating Conditions:-30 °C ~ 60 °C (-22 °F ~ 140 °F),Humidity 95% or less (non-condensing)
Power Supply:12 VDC ± 25%, PoE (802.3af Class3)
Power Consumption:12 VDC, 0.5 A, max. 6 W
PoE: (802.3af, 36V to 57V), 0.2 A to 0.1 A, max. 7.5W
Dimensions:Camera: Φ 70 mm × 155 mm (Φ 2.8" × 6.1")
Weight:Camera: approx. 410 g (0.9 lb.)
