hooking up a tow bar and locking the arms out-of-the-box demco tow bars are set up with the safety cables installed ready for you to tow install the light cable by placing the coil over the wire support rod secure the cable with the cable locking hairpin make sure your safety cables are criss-crossed underneath the pivot assembly and attach them to the chain anchors on the towed vehicle position the vehicle to be towed approximately 24 inches behind the towing vehicle the vehicles do not have to be in straight alignment to complete the hookup engage the towed vehicle and towing vehicle parking brakes take the top folded leg of the tow bar and extend upward to a 45 degree angle allowing the storage pin to clear the storage plate then unfold both legs making sure that the release triggers are on the inside of each leg when they are hooked up to each baseplate attaching point extend each l
