Introduction to Jeppesen Navigation Charts - 10011898

[Music] hello guys today I will show you how to understand the jeppesen airport chart so here we have a chart 10 9 for Vilnius International Airport in Lithuanian published on 2012 January 27th on the left we can see the airport elevation of 646 feet above the mean sea level and below that we can see the coordinates for the airfield reference point now below that we can see three frequencies one of them which is for air drum terminal information service 1 to 5 decimal 8 lit cargos handling 1 3 5 2 7 5 which is the ground handling and then this tower one one eight decimal to below all of this we can see a beautiful map for the area surrounding the airfield and the air fold itself in the middle we can see the runway runway 2-0 with the course of 195 and on the opposite direction runway 0 2 with the course of 0 1 5 degrees and around the runway of course we can see the whole apron with a f
