Description
Product description
CPE-80SR is an 11ac 5G outdoor CPE with LED display. It comply with 802.11ac Wi-Fi standard, data rate up to 450Mbps, Build in 11dBi panel antenna, the Wi-Fi range to up to 1000 meters.
High Gain Antenna for more range
With 11dBi MIMO high gain antenna, the point to pointWi-Fi rangeup to 1KM distance. What's more, it can supply the stable Wi-Fi signal for 15PCSIP Cameras in 500 meters.
Power over Ethernet
CPE-80R has integrated passivePower over Ethernet (PoE), for easy installation and lower cost. So it can be installed in areas where power outlets are not readily available, eliminating the mess of altering existing network infrastructure.
Multiple Operation and LED Display
CPE-80SR support gateway, wireless AP, Wi-Fi repeater, WDS operation mode, it can apply to almost wireless application scene; Then it with LED display to show AP/Client operation mode, Channels, IP address and Signal Strength; What's more, it is easy to setup CPE-80R's IP address, RF Power, Channels by set switch on product, no need to access into GUI, avoid the complex setup program, simple to check the working status.
TDMA Support
CPE80SR support HI-MAX TDMA Technology, use polling to solve the hidden node and resource waste problem between the CPE and base station, provide low latency, high throughput in PTP/PTMP application like IP camera wireless monitoring, long range Wi-Fi Transmission.
Access Controller System & Cloud Management System( work with KuWFi AC ONLY )
With Access Control System under AP operation mode, easily access advanced network settings through PC, like AP status monitor, change IP address, ESSID, Channel, Password, upgrade firmware, backup and restore.
Then work with Cloud Management System, easy to do central and remote management, advertisement and multiple authentication make this AP more professional in Wi-Fi Projects.
