Docooler Seven Tube AM Radio Kit, HX108-2 Seven Tube AM Radio Kit 525-1605KHZ DIY Semiconductor Radio Eletronic Kit

all right it's Chinese kit time this one is a radio I don't remember what kind of radio it's FM or AM let's take a look get up the tree this is a skew number one five nine three four seven one two seven two five two four five take a look [Applause] it's all in Chinese it's like an AM radio it looks like it has a ferrite Fantana let's take a look at the schematic we don't need to be able to read Chinese for this so one two three four five six seven seven transistor radio so it's easy to start from the back we have a a dome speaker and it's being driven with a transformer a push-pull Class B amplifier and it's being driven with a transformer and there's a driver transistor here so three transistors are just for the amplifier for the speaker then we have a I F can one two three four maybe I F cans five maybe so one of these is probably an AIA filter detector amplifier preamplifier then the
