Description
Basic Information
Chipset:By CPU
Size:156 x 127 x 37mm
Power Consumption: 10W
Operating Temp.:0~50 Degrees Celsius
Non-Operating Temp.:-20~80 Degrees Celsius
Processor Graphics:Intel HD Graphics
Onboard LAN:4 x Intel I211-AT Gigabit LAN
Onboard CPU:Intel Celeron BayTrail SOC J1900 Quad Core Processor 2.0GHz,Up To 2.42GHz 2M Cache
Memory:2GB DDR3L SO-DIMM 1333/1600 MHz 1.35V, 1 x Memory Slot, Up to 8GB Memory
Hard Disk:256GB mSATA SSD
Wireless:WiFi (Only for USB Device)
Front I/O:
1 x Power on/off Button
1 x Power LED
3 x USB 2.0
1 x USB 3.0
1 x VGA
Internal Connectors:
1 x Minipcie (For mSATA SSD)
1 x Minipcie (For USB Device)
1 x DDR3L SO-DIMM Memory Slot
1 x SATA
1 x SATA Power
1 x Automatically Boot Jumper
1 x RS232 Header (Optional)
1 x SIM Card Slot (Optional)
Rear I/O:
1 x DV 12V Input
1 x Power LED
1 x HDD LED
4 x RJ-45
1 x WiFi (For USB Device)
Package Included:
1 x Mini PC
1 x Screws
1 x Power Supply
1 x VESA Mount Bracket
2 x Antennas
Please Note:
1) It only supports AP-mode.
2) Height is too thin to install 2.5" HDD, so it only can support mSATA SSD.
3) It will be come with Pre-installation Unactivated Windows 7 in English for test without any Windows license. Press F11 key boot from USB Drive, press Delete key enter into BIOS.
4) Mini-PCIE cann't support WiFi and 3G/4G module at the same time in this computer. Half-length Mini-PCIE is only for WiFi, full-length is only for 3G/4G. It is Half-length by default.
Warranty:
1) Warranty is one year from you purchase.
2) This device fits for a LAN or WAN router, firewall, proxy, WiFi access point, VPN appliance, DHCP Server, DNS Server, IDS/IPS, et
