Allen Bradley 1734-Ep24dc, Series B, Expansion Power Supply, 24Vdc 1734-Ep24dc Ar Series B

welcome to module 1.1 ControlLogix hardware overview ControlLogix is one of the largest control systems provided by allen bradley it is very quickly identified by the number 1756 which is going to be specified on every single module which is going to be compatible within this family let's take a quick look at the website which allows us to select some of the part numbers for control logic systems so what you will quickly notice is that there's going to be two distinct identifiers when you're selecting parts or control logics and that's not to be confused with the family number so first and foremost you have different families of controllers as you can see here there's going to be 55 eight zeros fifty-five seven zeros and some other modules of which we're going to look at a later point that being said if you click on this link and decide to select the different modules for control logics
