Allen-Bradley 1747-L524 Processor Unit

here we have a slick 503 which happens to have Beaufort the ports that you can use with the 1747 UIC the top one looks like an Ethernet port but it is actually an rs-485 port which usually with the UIC is configured for D H 485 and that is its default setting and it would use the 1747 UIC bottom port by default is going to be DF 1 which you will not need the UIC 4 you will actually connect it with a 1747 CP 3 now you'll need the 1747 CP 3 to connect the UIC to this port if it happens to be configured for D H 485 but I'll say in 95 percent or maybe even 98 percent of the applications this does not need the UIC only this top port this 1747 UIC comes with two ports on it you have the rs-485 port which can be used on the slick 501 Slick's 502 and the slick 503 stop port along with some panel views and you have the rs-232 port which can be used on the slick 503 s bottom port the slick 504 is
