Allen-Bradley | 1756-L55M12/A | Logix5555 Processor 750KB Memory Series A (Renewed)

Hello and welcome to pdfsupply.com. Today we're going to be testing an Allen-Bradley ControlLogix processor. I have hear a 1756-L61 processor. It's being powered up by a 1756-PA72 power supply. I have the processor in a 1756-A6 rack. It's a six-slot rack which is otherwise empty because our test is going to be solely on the processor itself. There won't be any IO involved. Our goal is to get the processor into run mode and just test its working capability and its health, have it retain in run mode, and if we feel that there is or was an error we can go through and check in the RSLogix 5000 software in the errors and a fault screen and I'll show you guys how to do that in just a moment. The first thing we're going to do is since we have it powered up - and as you can see I've got it connected what's RS-232 cable to our computer here - I'm going to go to RSLinx Classic. This is the softwa
