Camera
Sensor: 1/2.7", 5.0 megapixel, progressive scan, CMOS
Lens: 4.0mm@F2.0 6.0mm@F2.0
Adjustment Angle: Pan: 0° ~ 360° Tilt: 0° ~ 90° Rotate: 0° ~ 360°
Shutter: Auto/Manual, 1 ~ 1/100000s
Minimum Illumination
Colour: 0.01Lux (F2.0, AGC ON)
0Lux with IR on
Digital Noise Reduction: 2D/3D DNR
Day/Night: IR-cut filter with auto switch (ICR)
S/N: >52dB
IR Range: Up to 30m (98ft) IR range
WDR: DWDR Video
Video Compression: Ultra 265, H.265, H.264, MJPEG
H.264 code profile: Baseline profile, Main Profile
Frame Rate
Main Stream: 5MP (2592*1944), Max 20fps;
Sub Stream: 720P (1280×720), Max 20fps
Privacy Mask: Up to 4 areas
ROI: Up to 2 areas
Motion Detection: Up to 4 areas
Smart
Behavior Detection: Intrusion, Motion detection,Tampering alarm
Intrusion: Enter and loiter in a pre-defined virtual region
Network
Protocols: IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SSL, QoS
Compatible Integration: ONVIF (Profile S, Profile T), API
Interface
Network: 10/100M Base-TX Ethernet
General
Power
DC 12V±25%, PoE (IEEE 802.3af)
Power Consumption: Max 4W
Dimensions: (L × W × H) 167.3 × 62.9 × 62.7mm (6.6" × 2.5" × 2.5")
