What's new with the ARRIS X220 PRO V2 Version?
1. The fight controller is upgrade from F3 to OMNIBUS F4 flight controller.
2. The ESC is upgrade from the 30A 4IN1 ESC to 40A 4IN1 ESC with BLHELI-S firmware, which supports Oneshot125 , Oneshot42 and Multishot,Dshot150, Dshot300 and Dshot600
3. Add the LED on the tear of the quad.
4. Antenna is upgrade from 4-leaf antenna to Pagoda one.
It is assembled and tested before leaving the factory. When you receive it, you need to install your own receiver (ARF)on it or bind with your own radio(BNF) and do some settings in Betaflight, then you can fly.
Specifications:
Diagonal Wheelbase: 220mm
Flight Controller: F4 flight Controller
Frame Material: Pure Carbon Fiber
BNF weight: About 356g
Camera: Runcam Swift 2 FPV camera
FPV TX: 5.8G 48CH (0mw/25mw/100mw/200mw/400mw/600mw Switchable)
Antenna: 5.8G pagoda Antenna
Flying Time:about 10 minutes hovering
Package Include:
1 x ARRIS X220 FPV Racing Quad Frame (ASIN: B071RC5LQ7)
4 x EMAX RS2306 2400KV Brushless Motor
1 x Flycolor Raptor S-Tower BHeli-S 2-4S 4-in-1 40A ESC + F4 + PDB + OSD
4 x ARRIS 5042 3-blade Propeller (ASIN: B01EWUQNOA)
1 x Runcam Swift 2 FPV Mini Camera
1 x ARRIS VT5804 Switchable VTX (ASIN: B07BM24JLB)
1 x Foxeer 5.8G pagoda pro antenna (ASIN: B07C91QVM2)
1 x ARRIS Buzzer
2 x Battery straps
Other equipment required (not included):
Radio Set: Suggest Jumper T8SG V2 Plus (B07C181HRN)
Battery: Suggest ARRIS 4S (B01I37E3BS)
Battery Charger: Suggest Skyrc Imax B6AC V2 (B01MZ1ZZ7Z)
Goggle: Suggest Aomway Commander V2 (B07C4V51RJ)
