Description
2 Series 18650 battery 6.4V 7.2V Lithium iron phosphate protection board Features: 1) high-accuracy voltage detection circuit. 2) terminal of the charger using high voltage device. 3) Built-in three-stage over-current detection circuit (over-current 1, over-current 2, or load short circuit). 4) MOS transistor can control the battery charge and discharge. 5) low standby current consumption. Parameter: Over charge voltage:3.65v±0.05v Over dishcarge voltage: 2.0-3.0v±0.05v Max continuous current:5A Max peak current:7A Working temperature:-40---+50 Storage Temperature:-40-- +80 Small current:less than 5uA Life cycle :more than 50000hours Resistance:Less than 300mΩ Short cut protection :Protectable,charge can repair Size: 38*8*2mm 2S BMS Cnnection instruction: B+ Connect battery positive. B- Connect battery negative. MB Connect the point between battery1 & battery 2. P+ Charge/discharge positive. P- Charge/discharge negative Notice: 1) Please note that the input and output voltage, and load current conditions for power protection board does not exceed the electrical parameters of the allowable power consumption. 2) special attention to the load current can not work long hours between maximum continuous operating current and over-current protection current. 3) When connecting the battery ,it may not discharge. In this case, connect the charger can be restored to normal working condition. 4) Although the BMS built-in electrostatic protection circuit, but please do not hand touch when BMS in the working condition, so as to avoid damage from static electricity protection board. SMT Workshop: You may like: Item specifics: Operating temperature: 25-45 Condition: New Mode
Batcus 2pcs/a lot 2S 5A Lithium Iron Phosphate 6.4V 7.2V BMS PCM Battery Protection Board BMS pcm for lifepo4 Battery - (Color: 3.7V 2S5ABLA2)
Current Price
$10.19
Average
$10.19
Min Price
$10.19
Max Price
$10.19
Price dynamics
0%
Description
2 Series 18650 battery 6.4V 7.2V Lithium iron phosphate protection board Features: 1) high-accuracy voltage detection circuit. 2) terminal of the charger using high voltage device. 3) Built-in three-stage over-current detection circuit (over-current 1, over-current 2, or load short circuit). 4) MOS transistor can control the battery charge and discharge. 5) low standby current consumption. Parameter: Over charge voltage:3.65v±0.05v Over dishcarge voltage: 2.0-3.0v±0.05v Max continuous current:5A Max peak current:7A Working temperature:-40---+50 Storage Temperature:-40-- +80 Small current:less than 5uA Life cycle :more than 50000hours Resistance:Less than 300mΩ Short cut protection :Protectable,charge can repair Size: 38*8*2mm 2S BMS Cnnection instruction: B+ Connect battery positive. B- Connect battery negative. MB Connect the point between battery1 & battery 2. P+ Charge/discharge positive. P- Charge/discharge negative Notice: 1) Please note that the input and output voltage, and load current conditions for power protection board does not exceed the electrical parameters of the allowable power consumption. 2) special attention to the load current can not work long hours between maximum continuous operating current and over-current protection current. 3) When connecting the battery ,it may not discharge. In this case, connect the charger can be restored to normal working condition. 4) Although the BMS built-in electrostatic protection circuit, but please do not hand touch when BMS in the working condition, so as to avoid damage from static electricity protection board. SMT Workshop: You may like: Item specifics: Operating temperature: 25-45 Condition: New Mode
Price will be lower
in next 2 weeks
in next 2 weeks
According to the data, price will be lower in next two weeks, so not waste your money and track better price!
