Belkin F1U125-KIT Bitronics Auto Switch Kit

here we are showing a standard non combo in close control unit and the kit required to field install a start/stop push-button we have the following part numbers eg n 0 5 0 1 AAA and kit number C 4 0 0 gk 3 step 1 and installing the C 400 G k3 kit is to take the cover off and remove the blank cover plate turn the door over and press the blank cover plate out step 2 is to mount the external face of the kit into the vacated slot on the cover you two screws will mount the external plate to the cover a Phillips screwdriver will be required step three is to assemble the internal sub assembly set the device with the buttons and wires in the mounting plate make sure the flat side of the mounting plate is flush with the wired device there are two sets of three pattern holes on the mounting plate insert the wired device into the top set of holes install C clamp to lock assembly in place a flat he
