Description
Camera
Image Sensor:1/3" Progressive Scan CMOS Min. Illumination:0.07Lux @ (F1.2, AGC ON) ,0 Lux with IR
Shutter time:1/25(1/30) s to 1/100,000 s
Lens:4mm@ F2.0 (6mm, 12mm optional) 2048 × 1536:
Angle of view: 70°(4mm), 43.3°(6mm), 20.6°(12mm) 1920 × 1080:
Angle of view: 79°(4mm), 49°(6mm), 23.2°(12mm)
Lens Mount:M12
Day& Night:IR cut filter with auto switch
Wide Dynamic Range:Digital WDR
Digital noise reduction:3D DNR
Compression Standard
Video Compression:H.264/M-JPEG
Bit Rate:32 Kbps ~ 16 Mbps
Dual Stream:Yes
Max. Image Resolution:2048×1536
Frame Rate:50Hz: 20fps (2048 × 1536), 25fps (1920 × 1080), 25fps (1280 × 720)
60Hz: 20fps (2048 × 1536), 30fps (1920 × 1080), 30fps (1280 × 720)
Image Settings:Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser
BLC:Yes, zone configurable
ROI:Yes, up to 4 configurable areas
Network
Network Storage:NAS
Alarm Trigger:Motion detection, Dynamic analysis, Tampering alarm
Protocols:TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,
PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour
Security:User authentication, watermark
System Compatibility:ONVIF, PSIA, CGI, ISAPI
Interface
Communication Interface:1 RJ45 10M / 100M ethernet interface
Reset Button:Yes
General
Operating Conditions:-30 °C ~ 60 °C (-22 °F ~ 140 °F)
Humidity 95% or less (non-condensing)
Power Supply:12 VDC ± 10%, PoE (802.3af)
Power Consumption:Max. 5 W (Max. 7 W with IR cut filter on)
Weather Proof:IP66
IR Range:-I: Approx 20 to 30 meters(65.6-98.4ft)
Dimensions:60.4×76.9×139.28 mm (2.4" × 3.0" × 5.5")
Weight:500g (1.1 lbs)
