Cisco Unified Communications 320W with FXO

hey what's going on YouTube and welcome to this video today we're going to be using the free lab beta and now setting up a SIP trunk from the Communications Manager to the 2811 gateway and then setup fxo and PRI interfaces to connect to the PSTN now as you can see from the diagram here on the PSTN extensions 8200 is set up for the FX 0 0 1 0 and 7200 is for the PRI so when we set up our dial plans we can have it where we set up you know as many digits as we want for the actual dial string but whether we do it in Communications Manager or at the gateway we want to make sure just those last 4 digits are sent across to be successful so to begin let's set up our SIP trunk from Communications Manager to the 28 11 and as you can see this is 1 9 to 1 6 8 2 o 2.2 so we're going to go over here to trunk and let me create a new SIP trunk here choose next and this one we can call the CM e 28 11 zi
