Connector Housing, IP68, DTP Series, Plug, 4 Positions, 6.71 mm, DTP Series Socket Contacts

DT family deutsche dt dt m and dt p series environmentally sealed connectors are designed as general purpose connectors providing reliability and performance at a low cost the dt series has thermoplastic housings are rectangular shape with inline printed circuit board or flange mounts they offer arrangements with two three four six eight and twelve cavities and accept size sixteen contacts the DTM series is a miniature series that offers arrangements with two three four six eight and twelve cavities and accepts size twenty contacts the DTP series is a power series that offers arrangements with two and four cavities and accepts size twelve contacts DT contact insertion begin with a crimped wire for assistance refer to the Deutsch contact video segment for detailed instructions refer to your wiring diagram to know which wire to insert into each cavity all cavities are marked with numbers
