camera
Image Sensor: 1/3" 4Megapixel progressive CMOS
Effective Pixels: 2688H)x1520(V)
Scanning System: Progressive
RAM/ROM ：256MB/16MB
Minimum Illumination: 0.31Lux/F2.2(Color), 0Lux/F2.2(IR on)
IR Distance: Distance up to 30m (98ft)
IR On/Off Control: Auto/ Manual
IR LEDs: 24
lens
Lens Type: Fixed
Mount Type: Board-in
Focal Length: 2.8mm
Max. Aperture: F2.0/F2.2
Angle of View: H: 106°~83°, V:56°~44°
Focus Control: Fixed
Close Focus Distance: N/A
PTZ
Pan/Tilt Range:Pan:0˚~360˚; Tilt:0˚~90˚;Rotation:0˚~360˚
Video
Compression: H.264+/H.264
Streaming Capability:2 Streams
Bit Rate Control: CBR/VBR
Bit Rate: H264H:80K ~ 10240Kbps
Noise Reduction: 3D DNR
White Balance：Auto/Natural/Street Lamp/Outdoor/Manual
Construction
Casing: Metal+Plastic
Dimensions: Φ70mm×164.7mm(2.76x6.49)
Net Weight: 0.38Kg (0.84lb)
Gross Weight: 0.44Kg (0.978lb)
