Camera
Image Sensor: 1/3" 4Megapixel progressive scan CMOS
Effective Pixels: 2592(H)x1520(V)
Minimum Illumination: 0.01Lux/F2.0 (Color), 0Lux/F2.0 (IR on)
IR Distance: 80m Lens
Focal Length: 3.6mm
Max. Aperture: F2.0
Angle of View: 77°
Intelligence
IVS (optional)Tripwire, Intrusion, Object Abandoned/Missing
Advanced Intelligent FunctionsFace Detection
Video
Compression: H.265/H.264/H.264B/H.264
Streaming Capability: 3 Streams
Frame Rate: Main Stream:PAL: 4M(1~25fps) NTSC:2M(1~30fps); Sub Stream: D1(1~25/30fps); Third Stream: 720P(1~25/30fps)
Bit Rate: 8Kbps~11.25Mbps
Day/Night: Auto(ICR) / Color / B/W
BLC Mode: BLC / HLC / WDR(120dB)
White Balance: Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control: Auto/Manual
Noise Reduction: 3D DNR
Motion Detetion: Off / On (4 Zone, Rectangle)
Region of Interest: Off / On (4 Zone)
Smart IR: Support
Privacy MaskingOff / On (4 Area, Rectangle)
Network
Ethernet: RJ-45 (10/100Base-T)
Interoperability: ONVIF, PSIA, CGI,GB/T28181
Edge Storage: NAS ,Local PC for instant recording
Smart Phone: IOS, Android
Electrical
Power Supply: DC12V, PoE (802.3af)
Power Consumption: <6.1W
Environmental
Operating Conditions: -40° C ~ +60° C B67 / Less than 95% RH
Ingress Protection: IP67
Construction
Casingplastic+Metal
Dimensions194mm×96mm×89mm
Net Weight0.64kg
Gross Weight0.8kg
