[Music] hi everyone this is will with KL aviation and in this lesson we're going to look at airport symbols on a VFR sectional chart for non-towered airports all right here we have three non-towered airports if talladega in the middle Anniston regional off to the east and st. Clair County off to the west now the first thing we can see is that all of these are magenta symbols now the magenta is going to indicate to us that there is no control tower at the field if there is a control tower it's going to be blue we'll go over towered airports in a separate lesson the next thing to notice is that there looks like a little bit of a runway diagram in each circle this actually is a diagram of what the runways look like at the airport in all of these cases there's only one runway but if there were two runways or three or as many as there are they will all be depicted now because these are solid
