DBParts DC Power Jack Cable Harness for HP 17-X027CL 17-X047CL 17-X127CL 17-X037CL 17-X087NR 17-X010NR 17-X020NR 17-X051NR 17-X061NR 17-X115DX 17-X116DX 17-X121DX 17-X173DX 17-x001cy 17-X114DX

the crimping process is the one of fitting the terminal pens to the end of our harness sections which are then going to get installed into the connector bodies now we have covered this process thoroughly and efi wiring fundamentals course however we have a slightly different example here which i'm going to go through that'll show you a couple of different details to be aware of the example that we're going to have a look at is going to be crimping an OEM terminal onto the end of a piece of shielded cable in this instance it is a Sumitomo DL o 9 O series connector and it's for the engine position sensor on our fd3s rx-7 that's the reason we've used our twisted shielded pair cabling now the first thing we're going to do is ensure that this harness section is actually the correct length when we've gone through the rest of the harness construction process we have left a little bit of extra
