Dell 5230n/5230dn/5350dn/ 5530dn/5535dn Fuser - 300000 Pages Yield [PN: CKP5W]

installing the maintenance kit in the Dell 55 30 55 35:53 50 and 50 to 30 series printers the fuser in your unit is going to be very hot so turn your machine off and allow it to cool for 30 minutes before beginning this procedure we'll start by turning off the power switch and then we're going to remove the power cord on the rear of the printer there's a top cap lift that straight up and then we'll remove the fuser cover wick pinch those clasps and lift out the fuser cover wick will open the rear door there's a retaining strap twist that to the side and that comes out and lifts the rear door off of its hinges the inner guide has two tabs push those tabs straight down and just fold that open you don't need to remove that there are two green tabs one on each side of the fuser press those inward and the fuser will slide out your new fuser will have some wedges in it remove each wedge there
