DELL #M266D 110V FUSER MAINT KIT FOR 2130CN

to maintain your Dell 2335 DN printer is suggested that you replace to fuse your maintenance kit every 70,000 pages this will help extend the working life of your printer and minimize jams and poor print quality the maintenance kit part number is d 2 3 3 5 - z1 it includes diffuser transfer roller and a pickup roller to remove the old fuse er first power off and shut down the machine the future will be hot so give it some time to cool down now open the back panel and using a Phillips head screwdriver unscrew the four screws in the fuser pull out the right side of the fuser first and then the left now slide the new feature in left side first and screw in the four screws to replace the pickup roller remove the tray and check to the base to machine on its back with the small piece of plastic holding the roller on the pick roller shaft and slide the pickup roller off slide the new roller on
