Dino-Lite AM4115ZTW Edge Handheld Microscope with Dual Focus, 1.3 MP, 2x - 50xThe AM4115ZTW Dino-Lite Edge delivers higher image quality with Larger Field-of-View (FOV) and Depth-of-Field (DOF), which makes it ideal for macro viewing applications. With a working distance of more than 1cm from the target, once in focus, rotating the knob will receive another focal point, and thus effectively zoom in the image optically. This offers the capability of looking into more detail while enjoying a larger field of view. The freely adjustable polarizer helps to reveal more detail or to enhance the contrast on the surface by reducing or eliminating the reflections. This model includes the adaptable cap design, a detachable and interchangeable front cap design used in the Dino-Lite Edge series. Different caps have been developed for more applications. Simply removing the cap would yield more working distance which brings added convenience in the higher magnification range, or have better accessibility to the full range of magnification.
Specification:
- BRAND: Dino-Lite
- MANUFACTURER PART NUMBER: AM4115ZTW
- WEIGHT LBS: 0.3 lbs
- DESCRIPTION: Edge Handheld Microscope with Dual Focus
- MATERIAL: ABS Plastic
- COLOR: Black
- SENSOR: CMOS
- MAGNIFICATION RANGE: 2X - 50X
- WORKING DISTANCE: Long
- TYPE: Digital Microscope
- OPERATING SYSTEM: Windows XP, Vista, 7, 8, 10, Mac OS 10.5+
- APPROVAL: CE, FCC
- LIMITED WARRANTY: 2 Years
- PACKAGE QUANTITY: 1
- SAVE FORMATS: BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX
- CALIBRATION FUNCTION: Yes
- FRAME RATE: Up to 30 FPS
- LIGHTING: 8 White LEDs
- DIMENSIONS: 10.5cm (L) x 3.2cm (D)
- MICROTOUCH SENSOR: Yes
- INTERFACE: USB 2.0
- MEASUREMENT FUNCTION: Yes
- PACKAGE INCLUDES: Microscope, Carry Pouch, Software CD, Calibration Target, Alternate End Caps
Dino-Lite AM4115ZTW Edge Handheld Microscope with Dual Focus, 1.3 MP, 2x - 50x
Dino-Lite AM4115ZTW Edge Handheld Microscope with Dual Focus, 1.3 MP, 2x - 50xThe AM4115ZTW Dino-Lite Edge delivers higher image quality with Larger Field-of-View (FOV) and Depth-of-Field (DOF), which makes it ideal for macro viewing applications. With a working distance of more than 1cm from the target, once in focus, rotating the knob will receive another focal point, and thus effectively zoom in the image optically. This offers the capability of looking into more detail while enjoying a larger field of view. The freely adjustable polarizer helps to reveal more detail or to enhance the contrast on the surface by reducing or eliminating the reflections. This model includes the adaptable cap design, a detachable and interchangeable front cap design used in the Dino-Lite Edge series. Different caps have been developed for more applications. Simply removing the cap would yield more working distance which brings added convenience in the higher magnification range, or have better accessibility to the full range of magnification.
Specification:
- BRAND: Dino-Lite
- MANUFACTURER PART NUMBER: AM4115ZTW
- WEIGHT LBS: 0.3 lbs
- DESCRIPTION: Edge Handheld Microscope with Dual Focus
- MATERIAL: ABS Plastic
- COLOR: Black
- SENSOR: CMOS
- MAGNIFICATION RANGE: 2X - 50X
- WORKING DISTANCE: Long
- TYPE: Digital Microscope
- OPERATING SYSTEM: Windows XP, Vista, 7, 8, 10, Mac OS 10.5+
- APPROVAL: CE, FCC
- LIMITED WARRANTY: 2 Years
- PACKAGE QUANTITY: 1
- SAVE FORMATS: BMP, GIF, PNG, JPG, TIF, RAS, PNM, TGA, PCX, MNG, WBMP, JP2, JPC, PGX
- CALIBRATION FUNCTION: Yes
- FRAME RATE: Up to 30 FPS
- LIGHTING: 8 White LEDs
- DIMENSIONS: 10.5cm (L) x 3.2cm (D)
- MICROTOUCH SENSOR: Yes
- INTERFACE: USB 2.0
- MEASUREMENT FUNCTION: Yes
- PACKAGE INCLUDES: Microscope, Carry Pouch, Software CD, Calibration Target, Alternate End Caps
