[Music] in today's video i'm going to show you how to wire up the doorking 1815 keypad to the doorking the 1838 series um on the door king 1815 we put the power into terminal blocks one and two with one being ground and two being positive uh the data zero and the data one in pins six and seven and that's going to come down towards the bottom on the bottom of the remote interface we have the 12 volt power positive negative we do have a backup battery wired in we have power going from the v bus over to the 1815 powering it and uh then we have the ground and then we have the data zero and uh the data one and then on the top of this we have our jumper put towards the back and we have uh that gives us a wet contact between normally open and ground we have it coming over here to our door strike so when it receives that wet 12 volts upon closure then it will open um if you you have just a gate
