[Applause] [Music] to remove and install the battery on your Ranger 570 follow these steps ensure the vehicle is on a flat level surface ensure the vehicle is in park turn the key switch to the off position and remove the key pull up on the rear of the seat remove it and set aside remove the two push rivets and lift the storage box to remove remove the black negative battery cable fastener set the cable aside caution the negative battery cable must be removed first to prevent arcing then remove the red positive battery cable fastener set the cable aside tip reinstall the cable fasteners into the battery posts to prevent miss placement remove the two battery bracket fasteners and remove the bracket if equipped remove the vent tube and slide the battery and bracket rearward lift the bracket and battery out of the vehicle if reinstalling the battery ensure it is fully charged caution using
