Description

The Electro-Voice EVID C8.2HC is an 8" coaxial transducer featuring an innovative waveguide (patent pending) that provides directivity control to 1 kHz. It provides much better music fidelity and speech intelligibility in spaces with high ceiling heights than typical flush units are capable of. Its 75° coverage pattern provides the same coverage area when used in a 21' ceiling as a typical flush mount mounted unit in an 8' ceiling. This loudspeaker system is a complete two-way ceiling loudspeaker package. The package consists of a bezel/waveguide assembly, grille, rear enclosure, 8" coax two-way loudspeaker with waveguide coupled titanium coated dome tweeter and internal line-matching transformer. The C8.2HC utilizes a transformer that offers a selection of 7.5 (70 V only), 15, 30 or 60 watts delivered to the loudspeaker system using either 70 V or 100 V lines, or 8 ohm bypass. Selection is via a convenient switch on the front of the waveguide. The perforated grille is finished in semi-gloss white powder-coated enamel. The baffle and bezel are constructed from UL 94V-0 rated ABS. The rear enclosure, with fiberglass damping material, provides an optimum internal volume for extended low frequency performance. A rear cover, with provisions for a junction box fitting, provides access to a 4-pin terminal block that allows direct connection to the speaker with 12 gauge wire and provides pass through to additional speakers. A tile bridge is included for safe suspension of the C8.2HC ceiling system in a drop ceiling that uses mineral wool, or other fiber-based ceiling tiles. The EVID line of ceiling speakers has been designed to work together as a complete system in a wide range of different ceiling constructions. They provide controlled dispersion, high-efficiency, high-maximum output, ease of installation, and wide-range reproduction of music or voice.

Electro-Voice C8.2HC Ceiling Speaker System

Price is below average

Get price

Current Price

$459

Average

$506.56

Min Price

$250

Max Price

$1 079

Price dynamics

Description

According to the data, price will be lower in next two weeks, so not waste your money and track better price!

Product review & video

hello this is david toller with supplemental seminary and i'm using my iphone now i just wanted to come to you and let you know that i've gotten into installing sound systems and sound boards and speakers and amps and all that good stuff so i wanted to show you the setup we have here at faith baptist we've recently installed with the help of many folks that helped me we were able to install and through a donation of our church be able to go digital and so this is a behringer x-32 32-channel a digital sound board or sound mixer i should say and so you can see it has all the processing up here the preamps gates compressors equalization and all that and then it has the screen over here to set each individual channel that i can change and do the eq on and so forth and it's on layers and so you have you know channels one through 16 or on one layer and then you get the next layer which got th
