Camera
Image Sensor:1/4"1Megapixel progressive scan CMOS
Effective Pixels:1280(H)x720(V)
Scanning System:Progressive
Electronic Shutter Speed:Auto/Manual 1/3(4)~1/10000
Min. Illumination:Color: 0. 1Lux/F1.2, B/W: 0.01Lux/F1.2,0Lux (IR on)
S/N Ratio: More than 50dB
Video Output:N/A
Camera Features
Max. IR LEDs Length :15m
Day/Night:Auto(ICR) / Color / B/W
Backlight Compensation:BLC/ HLC/ DWDR
White Balance:Auto/Manual
Gain Control:Auto/Manual
Noise Reduction:3D
Privacy Masking:Up to 4 areas
Lens
Focal Length:3.6mm
Max Aperture:F1.8
Focus Control:Manual
Angle of View:H: 70°
Lens Type:Fixed lens
Mount Type:Board-in Type
Video
Compression :H.264
Resolution:720P(1280×720)/ D1(704×576/704×480) /CIF(352×288/352×240)
Frame Rate: Main Stream 720P(1 ~ 25fps);Sub Stream:D1/CIF(1 ~ 25fps)
Bit Rate:H.264: 16K ~ 4096Kbps
Audio
Compression :N/A
Interface :N/A
Network
Ethernet:RJ-45 (10/100Base-T)
Wi-Fi:N/A
Protocol:IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP,
SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour
ONVIF:ONVIF Profile S
Max. User Access:10 users
Smart Phone :iPhone, iPad, Android
P2P :iPhone, Android Mobile App
Auxiliary Interface
Memory Slot :N/A
RS485:N/A
Alarm:N/A
PIR Sensor Range:N/A
General
Power Supply:DC12V 1A
POE :N/A
Power Consumption:<4W
Working Environment :-30°C~+60°C, Less than 95%RH
Ingress Protection:N/A
Vandal Resistance:N/A
Package Dimensions:150mm x90mm x85mm
Approvals:CE FCC RoHS
