this question test our ability to find our location using vo ours the question asks what is your approximate position on low altitude airway Victor one if the vor receiver indicates you're on the three hundred and forty degree radial of Elizabeth City vor the most common way to find a vor is to find the compass rose which is almost hidden with this Class C airspace also indicated here but here is our Norfolk vor and Airways extend from the vor s connecting to via wores and this question says victor one Southwest of Norfolk vor and here it is here's Victor one which is like a highway in the sky so we're somewhere along Victor one and what we need to do is draw a line from the Elizabeth City vor three hundred and forty degree radial and this is magnetic vor spoink to magnetic north not true north so we'll just draw a line here so we'll start the line at the Elizabeth City vor and we want
