moving on to number three i'm going to scroll up a little bit now this one's kind of interesting uh one thing that you're going to see right here is when you cut the top out of a cylindrical object it becomes shorter so do you see where if you projected this geometry straight across there's that and then you project this straight across it's a little bit taller and i don't know if you guys caught that but imagine you cut you know the top of the cylinder and you made a flat on it it's going to be shorter than the diameter of that cylinder so that's what we have we have a cut here that goes so far that's a visible edge here and then what is this hidden edge right here this hidden edge is this and this it's in alignment with that so then we have those hidden lines that go beyond that and one unit we start that cut again and then we have hidden lines for the hole if you can leave a little g
