Introducing the Harmony Audio Carbon series competition grade subwoofers that feature a massive 2.5" voice coil and at least 2000 watts power handling or more! The subwoofer features a carbon fiber paper reinforced cone with a high roll foam surround for maximum SPL excursion. The massive double stacked magnet motor delivers earth shattering bass response and power handling capabilities that simple cannot be matched. Live in Harmony!
Specifications:
- 10" Carbon Series Car Subwoofer
- Power Handling:
- Peak: 2000 watts
- RMS: 1000 watts
- Sensitivity: 85.7dB
- Frequency Response: 45Hz-300Hz
- Mounting Depth: 6-5/8"
- Mounting Cutout Diameter: 9-5/16"
- Min Sealed Box Volume (Cubic Feet): 0.99
- Max Sealed Box Volume (Cubic Feet): 1.94
- Min Vented Box Volume (Cubic Feet): 1.4
- Max Vented Box Volume (Cubic Feet): 2.47
- Magnet Weight: 202 Ounces
- 2.5" Copper Voice Coil
- Dual 2 Ohm
Features:
- Fiber Lightweight Cone
- Stitched High Roll Foam Surround
- Tinsel Leads Woven into Spider
- Die-Cast Aluminum Basket
- High Flux Ferrite Magnet
Detailed Specifications:
- Voice Coil Diameter: 65.5mm
- Voice Coil Height: 50mm
- HE Magnetic Gap Height: 15mm
- Voice Coil Bobbin: Black Aluminum
- Xmax: 17.5mm
- Magnet Layers: 4
- Cms (Suspension Compliance): 0.108
- Qms (Mechanical Q Factor): 4.3
- Qes (Electrical Q Factor): 0.52
- Qts (Total Q Factor): 0.5
- Mms (Moving Mass): 211.4
- Vas (Equivalent Volume of Compliance): 10.3 L
- Rs (Resonant Frequency): 45 Hz
- SD (Effective Piston Area): 363.05 cm2
Harmony Audio HA-C102 Car Stereo Competition Carbon 10" Sub 2000W Dual 2 Ohm Subwoofer New
Introducing the Harmony Audio Carbon series competition grade subwoofers that feature a massive 2.5" voice coil and at least 2000 watts power handling or more! The subwoofer features a carbon fiber paper reinforced cone with a high roll foam surround for maximum SPL excursion. The massive double stacked magnet motor delivers earth shattering bass response and power handling capabilities that simple cannot be matched. Live in Harmony!
Specifications:
- 10" Carbon Series Car Subwoofer
- Power Handling:
- Peak: 2000 watts
- RMS: 1000 watts
- Sensitivity: 85.7dB
- Frequency Response: 45Hz-300Hz
- Mounting Depth: 6-5/8"
- Mounting Cutout Diameter: 9-5/16"
- Min Sealed Box Volume (Cubic Feet): 0.99
- Max Sealed Box Volume (Cubic Feet): 1.94
- Min Vented Box Volume (Cubic Feet): 1.4
- Max Vented Box Volume (Cubic Feet): 2.47
- Magnet Weight: 202 Ounces
- 2.5" Copper Voice Coil
- Dual 2 Ohm
Features:
- Fiber Lightweight Cone
- Stitched High Roll Foam Surround
- Tinsel Leads Woven into Spider
- Die-Cast Aluminum Basket
- High Flux Ferrite Magnet
Detailed Specifications:
- Voice Coil Diameter: 65.5mm
- Voice Coil Height: 50mm
- HE Magnetic Gap Height: 15mm
- Voice Coil Bobbin: Black Aluminum
- Xmax: 17.5mm
- Magnet Layers: 4
- Cms (Suspension Compliance): 0.108
- Qms (Mechanical Q Factor): 4.3
- Qes (Electrical Q Factor): 0.52
- Qts (Total Q Factor): 0.5
- Mms (Moving Mass): 211.4
- Vas (Equivalent Volume of Compliance): 10.3 L
- Rs (Resonant Frequency): 45 Hz
- SD (Effective Piston Area): 363.05 cm2
