Description
Camera
Image Sensor:|1/1.8" Progressive Scan CMOS
Signal System:|PAL/NTSC
Shutter time:|1 s to 1/100,000 s
Lens:| 8-32mm
Auto Iris:|DC drive
Adjustment Range:|8-32 mm, F1.6, horizontal field of view: 42° to 13.5°
Focus:|Motorized VF lens
Compression Standard
Video Compression:|H.264+/H.264/MPEG4/MJPEG
H.264 code profile:|Baseline Profile/Main Profile/High Profile
Audio Compression:| G.711/G.722.1/G.726/MP2L2
Max. Image Resolution:|1920 x 1080
Frame Rate:|Main Stream: 50Hz: 50fps (1920 × 1080, 1280 × 960, 1280 × 720) 60Hz: 60fps (1920 × 1080, 1280 × 960, 1280 × 720)
Image Enhancement:|BLC /3D DNR/Defog/EIS
Image Settings:|Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser
Picture Overlay:|LOGO picture can be overlaid on video with 128 × 128 24bit bmp format
Network
Network Storage:|microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Alarm Trigger:|Road traffic, motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error
Protocols:|TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6
System Compatibility:|ONVIF (Profile S, Profile G),ISAPI
Interface
Communication Interface:|1 RJ45 10M/100M Ethernet port
Audio:|1-ch audio in, Mic in/Line in; 1-ch audio out
Audio Input:|1-ch 3.5 mm audio interface, MIC IN/LINE IN
Audio Output:|1-ch 3.5mm audio interface
Video Output:|1Vp-p Composite Output (75 Ω, BNC)
On-board storage:|Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
General
Operation Condition:|-30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing)
Power Supply:|12 VDC ± 10%, terminal block, PoE (802.3at, class 4)
Weather Proof:|IP67
IR
