Description
Support Upgrade Firmware.If you have some questions,The seller will help you.
Camera
Image Sensor: | 1/2.9" Progressive Scan CMOS
Signal System: | PAL/NTSC
Lens:2.8 mm, horizontal field of view: 81 degrees
Day and Night: | IR cut filter with auto switch
Wide Dynamic Range: | 120 dB
Digital noise reduction: | 3D DNR
Compression Standard
Video Compression: | H.265 plus/H.265/H.264 plus/H.264/MJPEG
Video bit rate: | 32Kbps~16Mbps
Max. Image Resolution: | 2560 X 1920
Frame Rate:50Hz: 20 fps (2560 X 1920), 25 fps (2560 X 1440, 2048 X 1536, 1920 X 1080, 1280 X 720) 60Hz: 20 fps (2560 X 1920), 30 fps (2560 X 1440, 2048 X 1536, 1920 X 1080, 1280 X720)
Image Enhancement: | BLC/3D DNR
ROI: | Support 1 fixed region for each stream
Network
Protocols: | TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6
System Compatibility: | ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI
Interface
Communication Interface: | 1 RJ45 10 trillion / 100 trillion Ethernet interface
On-board storage: | Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Smart Feature-set
Behavior Analysis: | Line crossing detection, Intrusion detection, Unattended baggage detection, Object removal detection
Intrusion Detection: | Enter and loiter in a pre-defined virtual region
Object Removal: Objects removed from the pre-defined region, such as the exhibits on display.
General
Operating Conditions: | negative 30 ~ 60 Celsius (negative 22 ~ 140 Fahrenheit)
Power Supply: | 12 VDC , PoE (802.3af Class3)
Weather Proof: | IP67
IR Range: | Up to 100 foot
Dimensions: | Camera: 70 X 155.03 Millimeter
Package: 216 X 121 X 118 Millimeter
Weight: | Camera: 0.9 pound
