Description
Camera Image Sensor 1/3" progressive scan CMOS Minimum Illumination 0.01lux @ (F1.2, AGC ON) , 0 lux with IR Shutter TIme 1/25 s to 1/100,000 s Lens 6 mm @ ƒ/2.0; angle of view: 46° Lens Mount M12 Day & Night IR cut filter with auto switch Digital Noise Reduction 3D DNR WDR Digital WDR Compression Standard Video Compression H.264 / MJPEG H.264 Type Main profile Video Bit Rate 32 Kbps to 16 Mbps Dual Streams Supported Image Maximum Resolution 1280 × 960 Maximum Frame Rate 30 fps (1280 × 960), 30 fps (1280 x 720), 30 fps (704 x 576), 30 fps (640 x 480) Image Setting Rotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web browser BLC Yes, zone configurable ROI Yes, up to 4 configurable areas Network Network Storage NAS Alarm Trigger Motion detection, tampering alarm Protocols TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour General Function User authentication, watermark, reset button Standard ONVIF, PSIA, CGI, ISAPI Interface Communication Interface 1 RJ45 10M/100M Ethernet port Reset Yes General Operating Conditions -22° F to 140° F (-30° C to 60° C); humidity: 95% or less (non-condensing) Power Supply 12 VDC ± 10%, PoE (802.3af) Power Consumption Maximum 5 W (maximum 7 W with ICR on) Environmental Rating IP66 IR Range 100 ft (30 m) Dimensions 2.4" × 3.0" × 5.5" (60.4 mm × 76.9 mm × 139.3 mm) Weight 1.1 lbs (0.5 kg)
