3M Scotchcast 82-A1 Inline Resin Power Cable Splice Kit, 5kV Voltage, Up to 2 AWG Conductor
Current Price
$40.44
Average
$30.92
Min Price
$15.15
Max Price
$51.68
Price dynamics
24%
Price will be lower
in next 2 weeks
in next 2 weeks
According to the data, price will be lower in next two weeks, so not waste your money and track better price!
Product review & video
Use the 3M Scotchcast-Brand Inline Resin Splice
Kit 82-A series to insulate and seal single-conductor, unshielded cable splices up to 5 kV and multiple
conductor cables through 1 kV. The 3M Brand 82-A series is UL Listed 486D,
File Number E102356. The 82-A Series Power Cable Splice kits are
designed for use in weather-exposed, direct-buried, or submersible locations. In this video, you'll see how to apply the
3M-Brand 82-A1 Power Cable Splice kit in 4 easy-to-follow steps. 1. Prepare the cable by thoroughly scrape
all wax and dirt 5 inches back from each cable end. 2. Make the connection according to instructions
for the connector being used. The mold will accept: a) Crimped-type connectors and b)
Split solder sleeve connectors. Then tape over connector area - Apply one
layer, half-lapped, Scotch-Brand Electrical Tape 23 over the connector area only. Do not wrap tape onto the penciled a
