DESCRIPTION:
Manifold auto protection: for the sake of your safety.
Ion flame inspection: to automatically shut down gas power under unexpected flameout.
Controller design: both cold water and warm water can be properly controlled.

FEATURE:
Gas Type: LPG Liquid Petroleum Gas (PROPANE)
Capacity:10L/min (2.6Gal), 25 degrees warm water producing rate
Working temperature:-8-45℃
Thermal input: 20KW
Thermal efficiency: ≥80%
Temperature rise: 25℃
Minimum working water pressure: 0.025MPa
Gas pressure: 2800Pa
Gas inlet: 9.5mm 3/8"
Gas pipeline (outer diameter): 20mm rubber gas hose
Water Inlet: G1/2''
Water Outlet: G1/2''
NPT 1/2" female to G 1/2" male
Vent Type:4.3" Flue Duct
Warranty: 3 years for parts
Certification: ISO 9001:2000
Digital Display with shower head
Automatic ignition system
Flame failure protection device
Water & gas combination unit
Fitted with overheating and pressure safeguard
Suitable for both summer and winter
20 min off self-timer
Mains power not required
Electrical requirement: DC3V, Automatic electric ignition powered by two (2) size 'D' batteries (batteries not included); No electrical hook up; No standing pilot;
Net weight: 7.2KG
