Description
Image Sensor 1/3" progressive scan CMOS Min. illumination 0.01 lux @ (F1.2, AGC ON), 0 lux with IR Shutter time 1/30s ~ 1/100,000s Lens 4mm @ F2.0 (6mm, 12mm optional) Angle of view: 75.8° Digital noise reduction 3D DNR Wide dynamic range True WDR 120db Day & night IR cut filter with auto switch Video compression H.264 / MJPEG / H.264+ Dual stream Yes Max. image resolution 4 MP CMOS, 2688×1520 Frame rate 20fps (2688×1520), 30fps (1920×1080) Image settings Saturation, brightness, contrast, sharpness adjustable through client software or web browser Network Storage NAS BLC Yes, zone configurable Alarm trigger motion detection, tampering alarm, network discon- nect, IP address conflict, storage exception Protocols TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS, FTP, 802.1x, Qos Interoperability ONVIF, PSIA, CGI Security User Authentication, reset button, flickerless, dual stream, heartbeat, mirror, watermark General functionalities User authentication, watermark Communication interface 1 RJ45 10M/ 100 M Ethernet interface Operating conditions -22 °F ~ 140 °F (-30 °C ~ 60 °C) humidity 95% or less (non-condensing) Power supply 12 VDC +/- 10%, PoE (802.3af) Power consumption Max, 7.5W Ratings IP66 IR range UP to 150ft Dimensions 11.8" x 3.4" x 3.35" (299 x 86.3 x 85mm) Weight 1.5lbs (700g).
