Image Sensor :1/2.5" Sensor

Min. Illumination:0.6 Lux @ F1.2, AGC On,1 Lux @ F1.6, AGC On,0 Lux with IR

Shutter Speed:1/25s~1/100,000s

Lens:3.5~9mm@F1.6,angle of view:92°~36°,Motorized VF lens

Lens Mount:Φ14

Auto Iris:DC drive

Day & Night:IR cut filter with auto switch

Video Compression:H.264 / MPEG4 / MJPEG

Bit Rate:32 Kbps ~ 16 Mbps

Dual Stream:Yes

Max. Resolution:2560×1920

Frame Rate:60HZ:7.5fps (2560 x 1920), 15fps (2048 x 1536), 30fps (1920 x 1080), 30fps (1600 x 1200), 30fps (1280 x 720)

50HZ:6.25fps (2560 x 1920), 12.5fps (2048 x 1536), 25fps (1920 x 1080), 25fps(1600 x 1200), 25fps (1280 x 720)

Image Settings:Saturation, brightness, contrast adjustable through client software or web browser

Network Storage:NAS (iSCSI optional)

Alarm Trigger:Motion detection, tampering alarm, network disconnect , IP address conflict, storage exception

Protocols:TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, SNMP, HTTPS, FTP,802.1x, Qos (SIP, SRTP, IPv6 optional)

Security:User authentication, watermark

Communication Interface 1 RJ45 10M / 100M ethernet interface and 1 RS-485 interface

Working Temperature:/Humidity:14°F~140°F(-10°C~60°C)

Humidity 90% or less (non-condensing)

Power Supply:12V DC ± 10%, PoE (802.3af)

Power Consumption:Max. 14W

Weather proof rating:IP66

IR Range:Approx.65~100ft(20~30m)

Dimension :3.86" × 3.49"×12.94"(98.0 ×88.6× 328.8mm)

Weight:3.75lbs(1700g )
