camera
Image Sensor: 1/2.9" 6Megapixel progressive scan CMOS
Effective: Pixels 3072(H) x 2048(V)
Scanning System:Progressive
Electronic Shutter Speed:Auto/Manual, 1/3~1/100000s
Minimum Illumination:0.002Lux( Color) 0.0002( black/white) 0Lux(IR on)
S/N Ratio:More than 56dB
IR Distance:Distance up to 50m
IR On/Off Control:Auto/ Manual
IR LEDs:1 Lens
Lens Type:Fixed
Mount Type:Board-in
Focal Length:3.6mm
Max. Aperture:F2.5/F2.2/F2.0 Angle of View3.6mm：H: 79° V: 69.4°
Focus Control:Fixed
Intelligence
IVS:Tripwire, Intrusion, Object Abandoned/Missing
Advanced Intelligent Functions:Face Detection
Video
Compression:H.265/H.264/MJPEG
Streaming Capability:3 Streams
Resolution:6M(3072x2048)/5M(2592x1944)/4M(2688x1520)/1080P(1920x1080)/720P(1280x720) D1(704x576/704x480) /CIF(352x288/352x240)
Bit Rate:14K ~ 10Mbps
Day/Night:Auto(ICR) / Color / B/W
BLC Mode:BLC / HLC / WDR(120dB)
White Balance:Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control:Auto/Manual
Noise Reduction:3D DNR
Motion Detetion:Off / On (4 Zone, Rectangle)
Region of Interest:Off / On (4 Zone)
Mirror:Off / On
Privacy Masking:Off / On (4 Area, Rectangle)
Network
Ethernet:RJ-45 (10/100Base-T)
Edge Storage:NAS,Local PC for instant recording
Web Viewer:IE, Chrome, Firefox, Safari
Management Software:Smart PSS, gDMSS, iDMSS, Easy4ip, Imou Smart Phone:IOS, Android
Note:
Camera is actived, default IP: 192.168.1.108),default account: admin, default password: admin
