RJ45/PROFINET Connector, EasyConnect ¬, 10/100 Mbps, Straight Entry - 700-901-1BB10

I'm going to show you an exciting new product from Phoenix Contact or rj45 filled wearable quick LAN connector it allows you to make up your Ethernet cables faster than you would ever imagine let's take a look how easy it is to do let's take a look at the components of this connector in front of us we have the coupling nut the connector housing and the connector body itself along with a piece of conductive foil tape what we need to do first before we assemble the connector is to strip back or even a cable taking the jacket off approximately 1 and 1/8 inches leaving approximately a quarter inch of the shoulding or braiding in this case exposed take your foil tape which is adhesive and wrap it around that braiding that's shoulding okay try to keep the tape is tight as you can ok once you've done that you want to start to assemble the connector you take the coupling nut and put it over top
