"A balance of size, budget, and fun-factor, that encourages anyone to create awesome HD FPV videos, without risking expensive equipment, breaking laws, or scaring spectators." - Tommy Tibajia

Design Goals

• Designed for the Runcam Split Mini camera
• Unibody design with rigid arm supports
• Vibration mitigating "clean & dirty" sections
• Proprietary Anti-Vibration Bushings
• Integrated FC soft mounts
• Adjustable camera placement
• 3 sets of 20x20mm mounting points
• Easy access to all USB and micro-SD ports
• Easy to build & maintain

• Unibody Main plate: 3mm bi-axial Toray Carbon Fiber
• Side plates (w/adjustable FPV cam placement): 2mm bi-axial Toray Carbon Fiber
• Battery plate (w/optional top mount FC holes): 1.5mm bi-axial Toray Carbon Fiber
• Hardware: Stainless Steel
• Frame Dampeners: Custom Poly-urethane
• Motor to Motor (diagonal): 163mm - Recommended Brat Motor
• Motor to Motor (front to back/side to side): 115mm
• Overall Frame size: 141x141mm
• Frame height: 55.5mm
• Dry Frame Weight: 54g
• Motor bolt pattern: 12x12mm
• Motor c-clip hole: 6mm

• 1x Frame Hardware set
• 1x Camera Hardware set
• 1x Camera Board Hardware set
• 1x FC/ESC Stack Hardware set
• 1x FC grommet
