Description
Camera
Image Sensor: 1/3" CMOS sensor
Effective Pixels: 2560x1440
Min. Illumination:Color: 0.01Lux/F1.2,AGC ON, 0.028Lux/F2.0,AGC ON
Smart IR, Distance 30m
Focal Length:2.8mm, horizontal FOV: 100°, vertical FOV: 55°, diagonal FOV: 117°
Day/Night: ICR, Support AGC,HLC,DWDR,BLC,3D DNR
Image Settings: Saturation, brightness, contrast and sharpness are adjustable via client software and web browser
Shutter Speed:1/3S ~1/100,000s;
Audio
Audio: Yes, Built-in microphone.
Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate: 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)
Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
Video
Video: H.265+/H.265/H.264+/H.264/MJPEG
Bit rate:32Kbps-16384Kbps
Network
Ethernet: 10/100Mbps, RJ45
Support WIFI. Wireless Standards: IEEE802.11b/g/n, 2.412~2.472 GHz; Wireless Range: 50m(164ft), The actual distance varies depending on the environment in which it is used.
API: ONVIF (Profile S/Profile G), ISAPI
Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, QoS, IPv6, UDP, Bonjour
User Access: Supports 6 channels simultaneous live view
Network Storage: Support built-in microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
Client: Hik-Connect, iVMS-4200, iVMS-4500,iVMS-5200
Web Browser: IE 8+, Chrome 31.0+, Firefox 30.0+, Safari 8.0+
Alarm Trigger
Motion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD error, HDD full
Certifications
Multi-Language
TF Card Slot: Support up to 128GB TF card(Not include)
Working Temperature & Humidity: -30°C to 60°C (-22°F to 140°F)/ ≤95%
Protection Level: IP66 standard
Power: DC12V/Max 6W; Item not included power adapter
Dimensions: Φ121.4×92.2mm (Φ4.8"×3.6"inch)
Net weight:0.467kg(1lb.)
