welcome to another max teen systems installation series video we will be installing a BNC male crimp on connector onto LMR of 195 coax this coax has a single braided shield and a solid Center conductor the max gain systems BNC male connector can easily be installed using standard stripping dimensions now let's get started with our installation we start out by sliding the connector ferrule on to the coax grab the BNC male body and line up the top of the neural grip ring with the end of the coax place a mark or use your thumbnail to mark where to cut the black jacket of the coax which should be 5/8 of an inch from the fresh cut end of the coax grab your knife or utility blade to cut around the coax where you marked it be sure not to cut too deep as to cut through the braided shield we are going to need as many strands as possible later cut through the outer black jacket only pull off the
