AirPrime® MC7430 Specifications:

Cellular:
•FDD/TDD LTE (Cat 6) 1,3,5,7,8,18,19,21,28,38,39,40,41
•Carrier Aggregation 1 +(8,18,19,21);3+(5,7,19,28);7+(5,7,28);19+21 38+38, 39+39, 40+40,41 +41
•DC-HSPA+ (42/5.76 Mbps) 1,5,6,8,9,19
•TD-SCDMA39

Physical Characteristics:
•Mini card 51 X 30 X 2.75 [mm]
•USB 3.0
•GPIOs for antenna tuning and SAR control
•PCM/I2S interface for voice (Future FW update)

Temperature ranges:
•-3OC to +70C (operating class A)
•-40C to +85C (operating class B)
•Storage Temperature:-40C to +85C

Key Features:
•Qualcomm MDM9230 chipset
•Single SKU for APAC
•GNSS
•Dedicated GPS connector with GPS bias or shared on diversity (TBD)
•GPS, Glonass, Galileo,BeiDou
•SUPL 1.0, 2.0, XTRA2.0
•Optional support for VoLTE and CSFB voice through future FW update
•Low power consumption
•Envelope tracking
•Software
•Gobi API,Image switching, MBIM interface
•Basic and Extended AT Commands
•Skylight for Windows 7, 8/8.1,10
•Linux and Android

Approval & Certification:
•JRF/JPA,NCC
•docomo, Telstra, Others TBD
