Thomas and Betts TC105 Aluminum Mounting Base, Screw Mounting with #10 Screw

hello my name is rich howard owner of architectural builder supply this video is to bring you a closer look at the crl number 8025 satin aluminum sex bolt for hardware mounting 2 inch and 3 4 thick doors this is a package of sex bolts is what it is sex bolts like this are used in lots of applications is where you'll use them but first let's do a bit of a tour of what's in the package there'll be four of these female ends okay and then there are four of the male ends they are quarter 20 is what they are let's take some dimensional properties of everything right now okay the overall length of the female end is 1.772 overall is 1.772 the dimension from the underside of the head to the end is 1.654 1.65 the diameter of the body itself is 0.373 0.373 the diameter of the head is 0.628 0.628 that's the female side the quarter 20 male side the length of those flathead machine bolts is 0.974 0.9
