camera
Image Sensor：1/2.5" 8MP IMX274 CMOS
Effective Pixels：3864 (H) × 2202 (V) approx. 8.51M pixels
Electronic Shutter：AUTO, AUTO, 1/25s ~ 1/100000s
Min. Illumination：0.05Lux@F1.2(AGC ON), 0Lux IR on
Day/Night：Auto/Color/(B/W)/Timing
WDR：Digital WDR
White Balance：Auto/Manual
AGC/BLC：Support
DNR：2D/3D DNR
Other：Motion Detection, Privacy Mask, Flip, Mirror
Encode
Embedded Solution：Hi3516A
Video Standard：H.264/H.265
Video Resolution：MainStream:15fps@8MP(3840x2160), 30fps@6MP(3072x2048),5MP(2592x1520),3MP/1080P/720P
Video Bitrates：Sub stream: 720x480/VGA(640x480)/360P/QVGA@30fps
IR Led
IR Led：20PCS SMD IR LEDs
IR Distance：30-40M
Lens
Focal length：2.8- 12 mm motorized zoom and AF lens
Audio
Bulit-in audio input
Network Services
Protocol：RTSP/DHCP/NTP/DST/FTP/SMTP
P2P：Yes
Web：IE , Firefox, etc.
Media：CMS, Android, IOS
ONVIF：17.06 compatible
memory storage
Support SD card memory storage, UP to 128G
General
Network Port：1-RJ45, 100Mbps, POE optional
Power Supply：12 VDC ± 10%
Power Consumption：< 5 W
Operating Temp.：-30℃-(+60)℃, 10%-90%RH
