Rice Lake Scale, Hanging OS-45 45kg x 0.05kg/99lb x 0.1lb/99lb x 1oz Includes carrying case, (2) AA Batteries, manual Bottom hook fully attached, top hook removable

hi my name is Ken Bishop sales engineering director here at interface and I'm here to help you get started using your model 920 I programmable indicator and controller we're going to now connect the load cell sensor up to the 9:20 eye box so what we'll want to do is unscrew the screws from the back of the unit so we can have access then we're going to undo the cable cap cable gland cap and then insert the load cell wire through the cable gland cap and then through the cable gland and then into the box and then as we route it in we're going to wire the sensor into the 920 eye connector this particular 920 eye is a 4-channel today we're going to scale one of those four channels that will be scale or channel number one that's the position for it after we're done doing the wiring then we are going to secure the cable gland cap and that will hold the load cell wire in place and strain reliev
