Can charge for different types of Li-ion / IMR/LiFePO4: 26650,18650,20700,21700,

18490, 17700, 17500, 16340(RCR123), 14500, 10440，Ni-MH/Cd: AA, AAA, A, SC, C size

There's a 'MODE' button separately for each channel choosing the battery types, charging current and charging status tracking

1,Long press the 'MODE' button for 3 seconds to change the charging current for lithium batteries, you can change the charging current at any time

2,Short press the 'MODE' button to change the charging types of lithium batteries. If no setting, it will default as 1.2V Ni-MH or 3.7V li-ion battery automatically. You need to change the mode for 3.85V li-ion and 3.2V LiFePO4 battery

3,u It begins to charge the battery 5 seconds after your settings

4,Connect the 5V input port with USB cable inserting the battery then the digital indicator showing the voltage with "V" flashing(charge starts). When no battery is inserted or defective battery is inserted, the charger will have no any response showing "null" ; When the battery is fully charged, it shows "Full"

5,It can display the battery voltage , charge current, time and capacity by short press the 'MODE' button at any time during charging.

Specifications:

Input: Micro USB DC 5V/2A(min.)

Output voltage:DC 4.2V 2000mA*1pc; 500mA/ 1000mA*2pcs for Li-Ion

                        DC 4.35V 2000mA*1pc; 500mA/ 1000mA*2pcs for IMR

                        DC 3.65V 2000mA*1pc; 500mA/ 1000mA*2pcs for LeFePO4

                        DC 1.48V 500mA for NiMH/NI-Cd

Constant voltage charging with cut-off current less then 100mA

Standby current: No more than 15mA
