Description
Picture 1 is just a model of the product. When buying, look at the corresponding power in picture 2
DC output range: 12V, 0 ~ 3.0A
Output voltage accuracy: + 5%
Ripple: 120mV
Efficiency: 84%
The input voltage range is:90 to 264VAC/127 to 370VDC
Input surge current: cold start, 70A/230V
Leakage current: <0.25mA / 240VAC
Overload protection: over current point in 110% ~ 150%, automatic detection, automatic recovery
Over voltage protection: when the rated output voltage is 115% to 135%, turn off the output voltage and restart the recovery
Start up hold time: 230VAC full load, 500ms, 20ms, 50ms
Insulation characteristic: between input and output: 3KVAC
Operating temperature: -30 ~ +75 DEG C (see output curve)
Seismic resistance: 10 to 500Hz, 2G 10 minutes / cycle, XYZ each axis 60 minutes
Security certification: through UL1310, Class2, CAN/CSA, No.223-M91, CB, IEC61347-1, IEC61347-2-13, reference TUV, EN60950-1 design
EMC standards: Emission: EN55022 (CISPR22), class, B harmonic: EN61000-3-2, class, A, EN61000-3-3
EMC standard: anti-interference: EN61000-4-2,3,4,5,6,8,11, EN55024, class a light industry standard
MTBF 743 thousand and 500 hours, MIL-HDBK-217F (25 C)
Connection mode: input / output: UL standard, 18AWG * 2C (60cm)
Shell number: 975A
Size: 148 * 40 * 30MM (L * w * h)
Weight and packing: net weight: 0.34 kg, gross weight: 0.38 kg
35W 12V 3A LPV-35-12 MEAN WELL Waterproof LED Lighting Drive Switching Power Supply Constant Voltage 110V/220V AC-DC Transformer
Price is below average
Current Price
$19.69
Average
$21.02
Min Price
$19
Max Price
$24.68
Price dynamics
6%
Description
Picture 1 is just a model of the product. When buying, look at the corresponding power in picture 2
DC output range: 12V, 0 ~ 3.0A
Output voltage accuracy: + 5%
Ripple: 120mV
Efficiency: 84%
The input voltage range is:90 to 264VAC/127 to 370VDC
Input surge current: cold start, 70A/230V
Leakage current: <0.25mA / 240VAC
Overload protection: over current point in 110% ~ 150%, automatic detection, automatic recovery
Over voltage protection: when the rated output voltage is 115% to 135%, turn off the output voltage and restart the recovery
Start up hold time: 230VAC full load, 500ms, 20ms, 50ms
Insulation characteristic: between input and output: 3KVAC
Operating temperature: -30 ~ +75 DEG C (see output curve)
Seismic resistance: 10 to 500Hz, 2G 10 minutes / cycle, XYZ each axis 60 minutes
Security certification: through UL1310, Class2, CAN/CSA, No.223-M91, CB, IEC61347-1, IEC61347-2-13, reference TUV, EN60950-1 design
EMC standards: Emission: EN55022 (CISPR22), class, B harmonic: EN61000-3-2, class, A, EN61000-3-3
EMC standard: anti-interference: EN61000-4-2,3,4,5,6,8,11, EN55024, class a light industry standard
MTBF 743 thousand and 500 hours, MIL-HDBK-217F (25 C)
Connection mode: input / output: UL standard, 18AWG * 2C (60cm)
Shell number: 975A
Size: 148 * 40 * 30MM (L * w * h)
Weight and packing: net weight: 0.34 kg, gross weight: 0.38 kg
