Description
📢WHY CHOOSE US?
Best Design & Quality!
You can charge 1 to 4 battery one time!
Portable! come with USB cable!
Fit for for solar panel,Great for outdoor!
Fit for different type battery!
HOW TO USE:
1.MODE Buttons:While electricity is connected,
1) If you charge 3.2V or 3.85V Batteres,press hold MODE button to change the battery type(within 5 Secs after set up),
1.2V Ni-MH and 3.7V li-ion can be detected automatically,so it need set for only 3.2V and 3.8V battery;
2)change the charging current amount 4 current at any time during charging by press hold MODE button.
2.LED: While connect it to 5V input,all LED light up immediately,
1)If no battery is put in,500mAh LED keeps on and others will go out.
2)When battery is detected in,4 LED lights on and 3.7V LED keep flicker to indicate to set the battery type
if no operation,it begin to charge 5 seconds later automatically under detection,4 LED lights will display the charging status.
3)Tap the button can show the battery type for 5 seconds.
4)No electricity is connected, insert a battery charger shows the remaining battery volume.
3.USB output indicator:
When USB discharging port detected,indicator of battery volume will light up for 10 seconds and go out, press button to light up again.
Features:
Compatible: C Battery,SC Battery,Ni-MH Ni-Cd 1.2V Battery,Li-Fe 3.2V,Li-ion 3.7V,Li-ion 3.85V,26650,22650,26500,18650,18490,17670,17500,17355,16340,14500,10440
Note: It only could charging 2 large size battery at one time,like C,SC.26650,26500.
5V USB adapter(adaptor current 2A) is recommended.
Input : Micro USB DC 5V/2A.
Output:1.42V 4.2V±0.05V 3.65±0.05V 4.35±0.05V.
Current: 500mA*4 batteries,700mA*3 batteries,1000mA*2 batteries,2000mA *1 Battery.
Constant voltage, cut-off current: less than 100mAh.
Package include:
1x battery charger
1x USB cable
1x User guide b
